ZLINE 120 - 400 CFM 20 Inch Wide Range Hood Insert with Push Button Controls Stainless Steel
Alternate Image
Alternate Image
Alternate Image
Alternate Image
Alternate Image
Alternate Image
Alternate Image
ZLINE 120 - 400 CFM 20 Inch Wide Range Hood Insert with Push Button Controls Stainless Steel
Alternate Image
Alternate Image
Alternate Image
Alternate Image
Alternate Image
Alternate Image
Alternate Image

ZLINE 120 - 400 CFM 20 Inch Wide Range Hood Insert with Push Button Controls

Model: E690
|
Item: bci4198405

$387.02
Finish: Stainless Steel -
Special Order
placeholder
Free Shipping!
Leaves the Warehouse in 14 to 19 weeks
-
Return & Shipping Details

Details

Experience ZLINE Attainable Luxury® with industry-leading kitchen and bath products that provide an elevated luxury experience, all designed in Lake Tahoe, USA. This hood is a 400 CFM fully integrated range hood insert which provides quiet and efficient performance. Designed to fit seamlessly into your cabinetry, the E690's induction blower will effortlessly remove grease and smoke from your kitchen. This range hood comes equipped with a multi-speed push button control and dishwasher safe aluminum mesh filters. The E690 is easy to operate with 4 speed options and dual LED lights to beautifully illuminate your stove. The high-performance ventilation system provides powerful filtration without disturbing the ambiance of your dinner party. With its classic 430 grade black stainless steel, this range hood contains rust, temperature, and corrosion-resistant properties to ensure a durable vent hood that will last for years to come. Enjoy modern features, including built-in LED lighting for an illuminated culinary experience and dishwasher-safe stainless steel baffle filters for easy clean-up. The E690 is crafted with a durable design and will create clean air for your family for years to come. This UL and ETL listed range hood insert offers the easiest operation and installation in the industry.

Features:

  • Blower outputs up to 400 CFM to keep your kitchen free of cooking fumes and odors
  • Baffle filters effectively trap and filter out unwanted smoke, odors, and grease
  • 2 LED lights illuminate the cooking area (bulbs included)
  • 4 available speeds provide just the right amount of ventilation for any condition
  • Push button controls allow you to easily set the power level of your range hood
  • Constructed from 430 grade stainless steel for added durability
  • Fixed vent designed to fit standard (circular) ductwork that easily connects to the top of the range hood for external venting
  • This product ships in multiple boxes and will require minimal assembly upon arrival
  • Covered under 3 year parts and lifetime motor manufacturer warranties

Specifications:

  • CFM: 120, 400
  • Sones: 0.6, 2.5
  • Nominal Width: 20"
  • Width: 20-1/2"
  • Height: 11-1/2"
  • Depth: 77-1/16"
  • Duct Size: 6" Round
  • Height Above Cooktop: 30"
  • Amperage: 3.5A
  • Voltage: 110V
  • Wattage: 385W
Additional ZLINE Links

Manufacturer Resources

Installation Sheet

Dimensions and Measurements

CFM
120, 400
CFM (High)
400
Depth
77.0875 in.
Duct Size
6" Round
Height
11.5 in.
Height Above Cooktop
30"
Height Above Cooktop (Max)
36 in.
Height Above Cooktop (Min)
30 in.
Nominal Width
20 in.
Product Weight
20 lbs.
Width
20.5 in.

Dimensions and Measurements

CFM
120, 400
CFM (High)
400
Depth
77.0875 in.
Duct Size
6" Round
Height
11.5 in.
Height Above Cooktop
30"
Height Above Cooktop (Max)
36 in.
Height Above Cooktop (Min)
30 in.
Nominal Width
20 in.
Product Weight
20 lbs.
Width
20.5 in.

Included Components

Available Without Blower
No
Bulb Included
Yes
Convertible to Ductless / Recirculating
No
Ductless
No
Includes Remote
No
Light Included
Yes

Included Components

Available Without Blower
No
Bulb Included
Yes
Convertible to Ductless / Recirculating
No
Ductless
No
Includes Remote
No
Light Included
Yes

Characteristics and Features

Blower Type
Internal
Bulb Type
LED
Control Type
Push Button
Duct Discharge
Horizontal, Vertical
Filter Type
Baffle Filters
Fingerprint Resistant
No
Installation Type
Full Installation
Material
Stainless Steel
Number of Bulbs
2
Panel Ready
No
Smart Home
No
Theme
Modern

Characteristics and Features

Blower Type
Internal
Bulb Type
LED
Control Type
Push Button
Duct Discharge
Horizontal, Vertical
Filter Type
Baffle Filters
Fingerprint Resistant
No
Installation Type
Full Installation
Material
Stainless Steel
Number of Bulbs
2
Panel Ready
No
Smart Home
No
Theme
Modern

Electrical and Operational Information

Amperage
3.5
Frequency
60 Hertz
Sones
0.6, 2.5
Speeds
4
Voltage
110
Wattage
385
Watts Per Bulb
192

Electrical and Operational Information

Amperage
3.5
Frequency
60 Hertz
Sones
0.6, 2.5
Speeds
4
Voltage
110
Wattage
385
Watts Per Bulb
192

Warranty and Product Information

ADA
No
Approved for Commercial Use
No
Certifications
ETL
Country Of Origin
China
Energy Star
No
Manufacturer Warranty
3 Year Parts, Lifetime Motor
Outdoor Approved
No
Title 20 Compliant
No
Title 24
No

Warranty and Product Information

ADA
No
Approved for Commercial Use
No
Certifications
ETL
Country Of Origin
China
Energy Star
No
Manufacturer Warranty
3 Year Parts, Lifetime Motor
Outdoor Approved
No
Title 20 Compliant
No
Title 24
No
