Schlage Bowery Privacy Knob Set with Decorative Addison Trim - Pack of 4
Model: F40BWE716ADD-4PACK|Item: bci5126744
from theBowery Collection
$191.36
Finish: Aged Bronze -



2 In Stock




Finish: Aged Bronze -
2 In Stock
Aged Bronze
This package includes the following items
Details
Privacy: Privacy door hardware features a locking mechanism on the interior for use on bedroom and bathroom doors where locking is needed. The exterior side features a small pin hole to unlock the door hardware from the outside.
Features:
- Tested to exceed ANSI/BHMA Grade 2 security requirements
- Constructed of high quality materials for durability and dependability
- Installs easily with all necessary mounting hardware included
- Covered by Schlage's 5 year finish and limited lifetime mechanical manufacturer warranties
- Includes four (4) privacy knobs
Specifications:
- Backset: Adjustable 2-3/8" or 2-3/4"
- Cross Bore: 2-1/8"
- Edge Bore: 7/8"
- Door Thickness: 1-3/8" to 1-3/4"
- Handing: Reversible Left or Right
- Handle Width: 2-1/8"
- Handle Height: 2-1/8"
- Handle Projection: 2-3/8"
- Trim Width: 2-3/4"
- Trim Height: 4"
- Product Weight: 6 lbs.
- Latch Faceplate: Drive-In or Round Corner
Manufacturer Resources
Installation SheetDimensions and Measurements
Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
Bore Hole | 2-1/8" |
Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
Edge Bore | 7/8" |
Handle Height | 2.125 in. |
Handle Projection | 2.375 in. |
Handle Width | 2.125 in. |
Product Weight | 6 lbs. |
Trim Height | 4 in. |
Trim Width | 2.75 in. |
Dimensions and Measurements
Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
Bore Hole | 2-1/8" |
Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
Edge Bore | 7/8" |
Handle Height | 2.125 in. |
Handle Projection | 2.375 in. |
Handle Width | 2.125 in. |
Product Weight | 6 lbs. |
Trim Height | 4 in. |
Trim Width | 2.75 in. |
Characteristics and Features
Concealed Screws | No |
Function | Privacy |
Handing | Left, Reversible, Right |
Handle Design | Bowery |
Handle Material | Metal |
Handle Style | Knob |
Knob Shape | Flat, Round |
Latch Faceplate | Drive-In, Round Corner |
Locking Mechanism | Push Button |
Material | Zinc |
Panic Proof | Yes |
Rosette Shape | Square |
Theme | Modern |
Trim Design | Addison |
Characteristics and Features
Concealed Screws | No |
Function | Privacy |
Handing | Left, Reversible, Right |
Handle Design | Bowery |
Handle Material | Metal |
Handle Style | Knob |
Knob Shape | Flat, Round |
Latch Faceplate | Drive-In, Round Corner |
Locking Mechanism | Push Button |
Material | Zinc |
Panic Proof | Yes |
Rosette Shape | Square |
Theme | Modern |
Trim Design | Addison |
Warranty and Product Information
ADA | No |
ANSI Certification | A156.5 |
Approved for Commercial Use | No |
BHMA Certification | Grade 2 |
Certifications | ANSI, BHMA |
Collection | Bowery |
Fire Rated | No |
Manufacturer Warranty | 5 Year Finish, Limited Lifetime Mechanical |
Series | Addison |
Warranty and Product Information
ADA | No |
ANSI Certification | A156.5 |
Approved for Commercial Use | No |
BHMA Certification | Grade 2 |
Certifications | ANSI, BHMA |
Collection | Bowery |
Fire Rated | No |
Manufacturer Warranty | 5 Year Finish, Limited Lifetime Mechanical |
Series | Addison |
