Item # bci3120308
Craftmade Pro Energy Star 209 52" 5 Blade Ceiling Fan - Blades and LED Light Kit Included
Model: K11296|Item: bci3120308
from thePro Energy Star 209 Collection
Discontinued
We still have product details and accessories, scroll down to see them!
Discontinued
We still have product details and accessories, scroll down to see them!
Details
Features
- Integrated LED is guaranteed for 3 years
- Crafted from steel
- Comes with a white glass shade
- Fan is controllable by a pull chain
- Can be installed on vaulted ceilings
- Includes (1) 4" downrod
- Includes 17 watt Integrated LED lighting
- Capable of being dimmed
- Uses a standard AC motor
- UL rated for dry locations
- Energy star certified
- Limited lifetime manufacturer warranty on motor and 1 year manufacturer warranty on all other accessories
Dimensions
- Height: 10-3/4"
- Width: 52"
- Product Weight: 16.1 lbs
- Wire Length: 76"
- Shade Height: 2-7/8"
- Shade Width: 11"
- Shade Diameter: 6-15/16"
- Canopy Height: 2-1/16"
- Canopy Width: 5-1/8"
Blade Specifications
- Number of Blades: 5
- Blade Span: 52"
- Blades Included: Yes
- Blade Pitch: 12 Degrees (The Angle of Attack of the Blades; Steeper Blades Move More Air)
- Fan Blade Material: MDF
Motor Specifications
- Speeds: 3
- CFM high: 5045 (cubic feet per minute) RPM high: 178 , medium: 118, low: 76Reversible Motor: Yes
Electrical Specifications
- Bulb Base: Integrated LED
- Light Kit Included: Yes
- Bulbs Included: Yes
- Wattage: 17 watts
- Voltage: 120 volts
- Amperage: 0.53
- Color Temperature: 3000K
- Color Rendering Index: 80CRI
- Lumens: 1150
Dimensions and Measurements
Blade Pitch | 12 Degrees |
Blade Span | 52 in. |
Canopy Height | 2.09 in. |
Canopy Width | 5.12 in. |
CFM (High) | 5045 |
Downrod Size(s) | 4 in. |
Height | 10.72 in. |
Motor Size | 153 mm |
Product Weight | 16.14 lbs. |
Shade Diameter | 6.96 in. |
Shade Height | 2.9 in. |
Shade Width | 11 in. |
Width | 52 in. |
Wire Length | 76 in. |
Dimensions and Measurements
Blade Pitch | 12 Degrees |
Blade Span | 52 in. |
Canopy Height | 2.09 in. |
Canopy Width | 5.12 in. |
CFM (High) | 5045 |
Downrod Size(s) | 4 in. |
Height | 10.72 in. |
Motor Size | 153 mm |
Product Weight | 16.14 lbs. |
Shade Diameter | 6.96 in. |
Shade Height | 2.9 in. |
Shade Width | 11 in. |
Width | 52 in. |
Wire Length | 76 in. |
Included Components
Blades Included | Yes |
Bulb Included | Yes |
Controller Included | No |
Downrod(s) Included | Yes |
Light Kit Included | Yes |
Shade | Yes |
Included Components
Blades Included | Yes |
Bulb Included | Yes |
Controller Included | No |
Downrod(s) Included | Yes |
Light Kit Included | Yes |
Shade | Yes |
Characteristics and Features
Blade Finish | Bronze, Medium Wood, Nickel, White |
Bulb Base | Integrated LED |
Bulb Type | LED |
Bulb Visible | No |
Color Temperature | 3000K |
Control Type | Pull Chain |
Dimmable | Yes |
Fan Blade Material | MDF |
Fan Type | Hanging |
Glass Features | Frosted Glass |
LED | Yes |
Light Direction | Down Lighting |
Light Kit Compatible | Yes |
Material | Steel, Synthetic |
Motor | AC Induction |
Number of Blades | 5 |
Number of Light Source(s) | 1 |
Reversible Motor | Yes |
Shade Color | White |
Shade Material | Glass |
Shade Shape | Bowl |
Sloped Ceiling Compatible | Yes |
Theme | Traditional |
Characteristics and Features
Blade Finish | Bronze, Medium Wood, Nickel, White |
Bulb Base | Integrated LED |
Bulb Type | LED |
Bulb Visible | No |
Color Temperature | 3000K |
Control Type | Pull Chain |
Dimmable | Yes |
Fan Blade Material | MDF |
Fan Type | Hanging |
Glass Features | Frosted Glass |
LED | Yes |
Light Direction | Down Lighting |
Light Kit Compatible | Yes |
Material | Steel, Synthetic |
Motor | AC Induction |
Number of Blades | 5 |
Number of Light Source(s) | 1 |
Reversible Motor | Yes |
Shade Color | White |
Shade Material | Glass |
Shade Shape | Bowl |
Sloped Ceiling Compatible | Yes |
Theme | Traditional |
Electrical and Operational Information
Amperage | 0.53 |
Color Rendering Index (CRI) | 80 |
Energy Efficiency (CFM / Watt) | 78.82 |
Lumens | 1150, 1350 |
Power Source | Hardwired |
RPM (High) | 178 |
RPM (Low) | 76 |
Speeds | 3 |
Voltage | 120 |
Wattage | 17 |
Electrical and Operational Information
Amperage | 0.53 |
Color Rendering Index (CRI) | 80 |
Energy Efficiency (CFM / Watt) | 78.82 |
Lumens | 1150, 1350 |
Power Source | Hardwired |
RPM (High) | 178 |
RPM (Low) | 76 |
Speeds | 3 |
Voltage | 120 |
Wattage | 17 |
Warranty and Product Information
Certifications | UL |
Collection | Pro Energy Star 209 |
Country Of Origin | China |
Energy Star | Yes |
Location Rating | Dry Location |
Manufacturer Warranty | Limited Lifetime, 1 Year |
Warranty and Product Information
Certifications | UL |
Collection | Pro Energy Star 209 |
Country Of Origin | China |
Energy Star | Yes |
Location Rating | Dry Location |
Manufacturer Warranty | Limited Lifetime, 1 Year |
