The Little Giant 509215 has been discontinued
** See similar or replacement items below **
Item # bci2130502
Little Giant 9SN 110 GPM 115V Submersible Sewage Pump with 3" Discharge and 20' Cord
Model: 509215|Item: bci2130502
from the9SN Collection
Discontinued
We still have product details and accessories, scroll down to see them!
Discontinued
We still have product details and accessories, scroll down to see them!
Details
The 9SN Series submersible effluent pumps from Little Giant are specifically engineered to handle the tough demanding tasks of wastewater and effluent waste transfer with high efficiency and long term dependability. Ideal for use in residential, commercial, industrial, and agricultural applications with light to medium transfer demands.
Product Features:- 4/10 Horse Power with overload protection
- New cooler running motor which extends the life of the pump
- Designed for continuous duty
- Covered by 12 month limited warranty
- Handles 2" solids
- Cover made from: Cast iron
- Housing made from: Cast iron
- Impeller Type: Vortex
- Impeller made from: Nylon
- Switch Type: Mechanical float
- Single phase operation
- 20' Cord included
- cCSAus listed
- 4/10 Horse Power
- Voltage: 115V
- 8.5 Amp maximum operation
- 3" Discharge diameter
- Length: 11-13/20"
- Width: 6-4/5"
- Height: 11-2/5"
- Flow rates (GPH: gallons-per-hour):
- At 5 feet of head: 110
- At 10 feet of head: 75
- At 15 feet of head: 30
Dimensions and Measurements
Cord Length | 240 in. |
Discharge Diameter | 2 in. |
Height | 11.4 in. |
Length | 11.64 in. |
Maximum Diameter Solids | 2 in. |
Maximum Head Height | 20 in. |
Minimum Head Height | 5 in. |
Product Weight | 35.5 lbs. |
Shut Off Height | 240 in. |
Water Connection | 2" |
Water Pressure (Max) | 8.7 PSI |
Width | 6.8 in. |
Dimensions and Measurements
Cord Length | 240 in. |
Discharge Diameter | 2 in. |
Height | 11.4 in. |
Length | 11.64 in. |
Maximum Diameter Solids | 2 in. |
Maximum Head Height | 20 in. |
Minimum Head Height | 5 in. |
Product Weight | 35.5 lbs. |
Shut Off Height | 240 in. |
Water Connection | 2" |
Water Pressure (Max) | 8.7 PSI |
Width | 6.8 in. |
Characteristics and Features
Automatic | Yes |
Configuration | Submersible Pump |
Impeller Material | Nylon |
Material | Cast Iron |
Material Casing | Iron, Plastic |
Material Housing | Iron |
Shutoff Head in Feet | 20 |
Submersible | Yes |
Switch Type | Float |
Water Connection Type | NPT |
Characteristics and Features
Automatic | Yes |
Configuration | Submersible Pump |
Impeller Material | Nylon |
Material | Cast Iron |
Material Casing | Iron, Plastic |
Material Housing | Iron |
Shutoff Head in Feet | 20 |
Submersible | Yes |
Switch Type | Float |
Water Connection Type | NPT |
Electrical and Operational Information
Amperage | 8.5 |
Electrical Phases | 1 |
Frequency | 60 Hertz |
Horsepower | .4 |
Maximum Fluid Temperature | 140 °F |
Voltage | 115 |
Wattage | 920 |
Electrical and Operational Information
Amperage | 8.5 |
Electrical Phases | 1 |
Frequency | 60 Hertz |
Horsepower | .4 |
Maximum Fluid Temperature | 140 °F |
Voltage | 115 |
Wattage | 920 |
Warranty and Product Information
Approved for Commercial Use | Yes |
Certifications | CSA |
Warranty and Product Information
Approved for Commercial Use | Yes |
Certifications | CSA |
