Features:

• Passage Door Lever Set featuring the Carson Lever and Interior Push Button
• ANSI/BHMA A156.5, Security Grade 3
• Constructed from High Quality Steel
• Features a Reversible, Symmetrical Design for Right or Left Handed Doors
• Simple One-person Installation; No Extra Hands Needed
• Round Corner Latches Available
• Lifetime Mechanical, 5 Year Finish Warranty
• Lever Functions Meet 4.13.9 ADA Requirements
• Meets UL 3 Hour Rire Rating

Key Product Attributes:

• Privacy Function: Privacy levers feature a push button lock on the interior for use on bedroom and bathroom doors where locking is needed. The exterior side of this privacy leverset features a small slot to unlock the lever from the outside. Emergency release tool included (small key).

Specifications:

• Backset: Adjustable to 2-3/8" or 2-3/4"
• Cross Bore: 2-1/8"
• Edge Bore: 1" Standard
• Door Thickness: 1-3/8", 1-3/4"
• Handing: Reversible
• Lever Length: 3.80"
• Rose Diameter: 2.56"
• Lever Projection: 1.96"
• Latch Faceplate: Radius Corner
