The Haiku B3213-X4-AB-04-02-D-01-F531 has been discontinued
** See similar or replacement items below **
Haiku Indoor 84" 3 Blade DC Ceiling Fan with Smart Home Technology
Model: B3213-X4-AB-04-02-D-01-F531|Item: bci3526199
Discontinued
We still have product details and accessories, scroll down to see them!
Discontinued
We still have product details and accessories, scroll down to see them!
Details
Spanning 52- to 84-in. in diameter, Haiku fans are ideal for spaces of any size, including office and retail space, foyers, bedrooms and dining areas. Made of aircraft-grade aluminum, Haiku fans deliver silent air circulation with serious style. The Haiku boasts 75 international design and technology awards (and counting), including the prestigious red dot Award, a Product Innovation Award in the furnishings category by Architectural Products, and the Most Efficient of ENERGY STAR as recognized by the U.S. Environmental Protection Agency, among others. With SenseME technology, built-in motion, temperature and humidity sensors allow indoor Haiku fans to respond automatically to changing room conditions for maximum comfort, convenience and energy savings.
Included Components:
- 3 Aircraft-Grade Aluminum Fan Blades
- (1) 20" and (1) 32" Extension Tube
- Remote Control
- Canopy and Mounting Hardware (can be mounted on sloped ceilings)
Special Features:
- Available pairing with the Nest Learning Thermostat™ for additional energy savings
- Operates with handheld remote, Haiku Home mobile app, or with voice control through Amazon Alexa-compatible devices
- Energy Star certified (Most Efficient 2018)
- Provides 7 fan speeds, sleep mode, whoosh mode (simulates natural breeze), and timer
- Easy installation - no balancing required
- Limited lifetime motor warranty and a 3 year warranty on all other components
Fan Specifications:
- Blade Span: 84 Inches
- Recommended Installation Height: 9' to 18'
- CFM (High): 19292 (cubic feet per minute)
- RPM (High): 135
- Motor Type: DC Motor
- Voltage: 100-240V
Suggested Downrod Lengths:
- 8 - 9.5 Foot Ceiling: 6 or 12 Inch Downrod
- 9.5 - 11 Foot Ceiling: 23.3 Inch Downrod
- 11 - 13 Foot Ceiling: 36 Inch Downrod
- 13 - 14 Foot Ceiling: 52 Inch Downrod
- 14+ Foot Ceiling: 64 Inch Downrod
Manufacturer Resources
Installation SheetRemote User GuideRemote Mounting GuideWarranty InformationSpecification SheetSenseME SpecificationsDimensions and Measurements
Blade Span | 84 in. |
CFM (High) | 19292 |
CFM (Low) | 5983 |
Downrod Size(s) | 20, 32 in. |
Height | 29 in. |
Nominal Height | 29 in. |
Nominal Width | 84 in. |
Product Weight | 26 lbs. |
Width | 84 in. |
Dimensions and Measurements
Blade Span | 84 in. |
CFM (High) | 19292 |
CFM (Low) | 5983 |
Downrod Size(s) | 20, 32 in. |
Height | 29 in. |
Nominal Height | 29 in. |
Nominal Width | 84 in. |
Product Weight | 26 lbs. |
Width | 84 in. |
Included Components
Blades Included | Yes |
Controller Included | Yes |
Downrod(s) Included | Yes |
Includes Receiver | Yes |
Light Kit Included | No |
Included Components
Blades Included | Yes |
Controller Included | Yes |
Downrod(s) Included | Yes |
Includes Receiver | Yes |
Light Kit Included | No |
Characteristics and Features
App Compatibility | Amazon Alexa, Nest |
Blade Finish | Bronze, Nickel, Silver |
Control Type | Remote |
Device Compatibility | Smartphone, Amazon Echo, Android, iPad, iPhone, iPod Touch |
Energy Efficient | Yes |
Fan Blade Material | Aluminum |
Fan Type | Hanging |
Light Kit Compatible | Yes |
Material | Aluminum |
Motor | DC Motor |
Number of Blades | 3 |
Reversible Blades | No |
Reversible Motor | Yes |
Sloped Ceiling Compatible | Yes |
Smart Home | Yes |
Theme | Modern |
Wireless Communication | WiFi |
Characteristics and Features
App Compatibility | Amazon Alexa, Nest |
Blade Finish | Bronze, Nickel, Silver |
Control Type | Remote |
Device Compatibility | Smartphone, Amazon Echo, Android, iPad, iPhone, iPod Touch |
Energy Efficient | Yes |
Fan Blade Material | Aluminum |
Fan Type | Hanging |
Light Kit Compatible | Yes |
Material | Aluminum |
Motor | DC Motor |
Number of Blades | 3 |
Reversible Blades | No |
Reversible Motor | Yes |
Sloped Ceiling Compatible | Yes |
Smart Home | Yes |
Theme | Modern |
Wireless Communication | WiFi |
Electrical and Operational Information
Energy Efficiency (CFM / Watt) | 359.255121042831 |
RPM (High) | 135 |
Speeds | 7 |
Voltage | 100, 240 |
Wattage | 53.7 |
Electrical and Operational Information
Energy Efficiency (CFM / Watt) | 359.255121042831 |
RPM (High) | 135 |
Speeds | 7 |
Voltage | 100, 240 |
Wattage | 53.7 |
Warranty and Product Information
Certifications | ETL |
Collection | Indoor |
Country Of Origin | USA |
Energy Star | Yes |
Location Rating | Dry Location |
Made in America | Yes |
Manufacturer Warranty | 3 Year Parts, Limited Lifetime Mechanical |
Warranty and Product Information
Certifications | ETL |
Collection | Indoor |
Country Of Origin | USA |
Energy Star | Yes |
Location Rating | Dry Location |
Made in America | Yes |
Manufacturer Warranty | 3 Year Parts, Limited Lifetime Mechanical |
