Hafele Pivoting Pocket Door Hardware

Features:

• Unique scissor design allows for use with large and heavy wooden or glass doors
• May also be used to partition rooms
• Hardware is modular with up to four working configurations
• All components are installed into the intermediate panel so the hardware can be installed in the shop
• Hafele provides a one year limited warranty for their hardware

Kit Includes:

• 1 Upright with guide
• 1 Scissor assembly complete with 2 scissor assembly guides
• 5 Concealed hinges
• 1 Spacer profile
• 1 Guide track
• 1 Running track
• 1 Door stopper with clip-in door stopper
• 1 Running gear
• 1 Profile with guide brush and fixing clamps
• 1 Pair of cover caps
• 1 End position cushioning
• Mounting accessories

Specifications:

• Door Height: 7' 6-9/16" to 9' 4-3/16" (2301 to 2850 mm)
• Door Width: 11-13/16" to 35-7/16" (300 mm to 900 mm)
• Door Thickness: 3/4" to 1-15/16" (19-50 mm)
• Maximum Door Weight: 110 lbs (50 kg)
