Grundfos UPS 32-80 F B Canned Rotor 3x208-230V Bronze Recirculation / Circulator Pump

The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricatd by the pumped liquid. In order to avoid problems in connection with disposal, great importance has been attached to using as few different materials as possible.

Technical:

• Maximum operating pressure: 145 psi
• Approvals on nameplate: CUL

Material:

• Pump housing: Bronze
• Pump housing: DIN W.-Nr. 2.1176.01
• Impeller: Stainless steel
• Impeller: DIN W.-Nr. 1.4301
• Impeller: AISI 304

Installation:

• Range of ambient temperature: 32 .. 104 °F
• Maximum operating pressure: 145 psi
• Flange standard: USA Oval
• Type of connection: F
• Pipe connection: 32
• Pressure stage: 145 psi
• Port-to-port length: 11" mm

Liquid:

• Liquid temperature range: 14 .. 248 °F

Electrical Data:

• Power input in speed 1: 195 W
• Power input in speed 2: 235 W
• Max. power input: 280 W
• Main frequency: 60 Hz
• Rated voltage: 3 x 208-230 V
• Current in speed 1: 0.58 A
• Current in speed 2: 0.72 A
• Current in speed 3: 1.1 A
• Cos phi in speed 1: 0,84
• Cos phi in speed 2: 0,82
