Grundfos UP 1542 B5 Canned Rotor Pump with a Maximum Power Input of 95W and Bronze Construction

UP 1542 B5 Canned Rotor Pump with a Maximum Power Input of 95W and Bronze Construction

UP 1542 B5 The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid. The pump is characterized by: Ceramic shaft and radial bearings. Carbon axial bearing. Stainless steel rotor can and bearing plate. Corrosion resistant impeller, Composite, PES. Bronze pump housing. The motor is a 1 phase motor. No additional motor protection is required.

Technical:

• Maximum operating pressure: 145 psi
• Approvals on nameplate: UL, CSA

Material:

• Pump housing: Bronze
• Pump housing: DIN W.-Nr. 2.1176.01
• Impeller: Composite, PES

Installation:

• Maximum ambient temperature: 104 °F
• Ambient max at 176°F liquid: 176 °F
• Maximum operating pressure: 145 psi
• Flange standard: USA Sweat
• Type of connection: Bronze Sweat
• Pipe connection: 1/2" Sweat
• Pressure stage: 10
• Port-to-port length: 5 in

Liquid:

• Liquid temperature range: 35.6 .. 230 °F

Electrical Data:

• Number of poles: 2
• Max. power input: 95 W
• Rated power - P2: 0.04 HP
• Main frequency: 60 Hz
• Rated voltage: 1 x 230 V
• Current in speed 3: 0.41 A
• Capacitor size - run: 2 µF/400 V
• Insulation class (IEC 85): F
