Product Information:

• This Unit Is Too Large For Liftgate Service, Must Have A Shipping Dock Or Forklift


• Drive-Tek: Variable Speed Drive reduces energy demand up to 33%


• Standard Y-Delta Soft Start Motor: Reduced energy demand & amp draw on start up


• PLC Controller- Advanced Maintenance Intelligence Monitor
  • Monitors maintenance, temperature, oil level, filtration & hours
  • Allows convenient remote start/stop


• Spin-Tek
  • Unique easy access oil filters & air/oil separators
  • Requires no tools to remove or install- saving time & money


• Precision Engineered Rotary Air End
  • Highly efficient design provides maximum discharge
  • Rated up to 353.2 CFM at 100 PSI (145 PSI maximum)


• Heavy-Duty Sound Attenuated Cabinet
  • Provides lower decibel operation than a typical rotary screw unit
  • Rated at 78 dBA; 2" NPT air outlet


• Designed For Use With Stationary Air Receiver (Not Included): Air receivers can be purchased separately to meet your specific needs


• 1 Year Limited Standard Factory Warranty: 10 years on air-end pump and motor with purchase extended warranty service kit


• Must-Have Maintenance Kit To Keep Your EMAX Warranty In Force: SERVICEKIT019 Maintenance Kit required to validate warranty coverage

Specifications:

• Certifications: ASME, CSA, ETL, and UL
• Fuel Type: Electric
• Height: 65"
• Width: 51"
• Length: 54"
• Product Weight: 2220 lbs
• Warranty: 1 Year Commercial and 1 Year Residential

Included Accessories:

• Filter Included

Tank Specifications:

• Tank Outlet Size: 2"

Pump Specifications:

• Lubrication Type: Oil Lubricated
• CFM: 353
• Drive Type: Direct Drive

Engine and Motor Specifications:

• Horsepower: 75 HP
• Voltage: 460V
