The Broan L400K has been discontinued
** See similar or replacement items below **
Item # bci417671
Broan 415 CFM 3.3 Sone Ceiling or Wall Mounted Ventilator
Model: L400K|Item: bci417671
from theLoSone Select Collection
Discontinued
We still have product details and accessories, scroll down to see them!
Discontinued
We still have product details and accessories, scroll down to see them!
Details
Features:
- Features a powerful 415 CFM permanently lubricated and sealed motor that's specifically designed for continuous use applications
- Mounts directly to joists via mounting brackets which makes for an intuitive, straight-forward installation
- Compatible with a number of Broan multi-function and time control wall switches (sold separately)
- Not recommended for use over bathtubs and showers
Specifications:
- CFM: 415
- Sones: 3.3
- Duct Size: 4-1/2 Inch x 18-1/2 Inch
- Grill Width: 23.25 Inches
- Grill Length: 14 Inches
- HVI Certified: No
- UL Listed: Yes
- Light Included: No
- Housing Length: 21-1/2"
- Housing Width: 12-1/4"
- Housing Depth: 11-3/4"
Product Variations:
- L400: 434 CFM
- L400K (This Model): 406 CFM, for Kitchen Applications
- L500: 514 CFM
- L500K: 481 CFM, for Kitchen Applications
- L700: 701 CFM
Manufacturer Resources
Installation GuideInstallation ManualIndoor Air Quality GraphicSpecification SheetProduct SpecificationsDimensions and Measurements
CFM | 415 |
CFM (High) | 415 |
Duct Size | 4-1/2" x 18-1/2" |
Grille Length | 14 in. |
Grille Width | 23.25 in. |
Housing Depth | 11.75 in. |
Housing Length | 21.5 in. |
Housing Width | 12.25 in. |
Max Ventilation Area | 377 sq. ft. |
Product Weight | 36.2 lbs. |
Dimensions and Measurements
CFM | 415 |
CFM (High) | 415 |
Duct Size | 4-1/2" x 18-1/2" |
Grille Length | 14 in. |
Grille Width | 23.25 in. |
Housing Depth | 11.75 in. |
Housing Length | 21.5 in. |
Housing Width | 12.25 in. |
Max Ventilation Area | 377 sq. ft. |
Product Weight | 36.2 lbs. |
Included Components
Heater Included | No |
Light Included | No |
Motion Sensor | No |
Included Components
Heater Included | No |
Light Included | No |
Motion Sensor | No |
Characteristics and Features
Duct Discharge | Horizontal |
Function | Utility Fan |
Grille Finish | Whites |
Humidity Sensing | No |
Installation Type | Ceiling, Wall |
Material | Metal |
Night Light | No |
Characteristics and Features
Duct Discharge | Horizontal |
Function | Utility Fan |
Grille Finish | Whites |
Humidity Sensing | No |
Installation Type | Ceiling, Wall |
Material | Metal |
Night Light | No |
Electrical and Operational Information
Amperage | 1.4 |
Sones | 3.3 |
Speeds | 1 |
Voltage | 120 |
Wattage | 146 |
Electrical and Operational Information
Amperage | 1.4 |
Sones | 3.3 |
Speeds | 1 |
Voltage | 120 |
Wattage | 146 |
Warranty and Product Information
Approved for Commercial Use | Yes |
Certifications | UL |
Collection | High Capacity |
Country Of Origin | USA |
Energy Star | No |
Made in America | Yes |
Manufacturer Warranty | 1 Year Limited |
Warranty and Product Information
Approved for Commercial Use | Yes |
Certifications | UL |
Collection | High Capacity |
Country Of Origin | USA |
Energy Star | No |
Made in America | Yes |
Manufacturer Warranty | 1 Year Limited |
