Brizo Beauclere Sensori Single Handle Volume Control Valve Trim with Cross Handle - Less Rough In

Brizo T66666 Features:

• Covered under Brizo's faucet and finish lifetime limited warranty
• Constructed of brass ensuring durability and reliability
• Handle included
• Cross style handle
• Coordinates with products from the Beauclere line
• Must also order R35600 Rough-In - not included
• 90 degree handle rotation controls volume only
• Volume controls are required for every outlet and every set of body sprays (up to max flow)
• All parts are replaceable from the front
• Volume control only; must be used with temperature control device
• Rough can accommodate up to 3 1/4" wall thickness.
• NOTE: some applications may require stem extender RP100304
• Complies with ADA standards

Brizo T66666 Specifications:

• Height: 2-1/4" (bottom to top)
• Width: 3-3/8" (left to right)
• Volume control flows up to 16.2 gpm @ 60 psi
• Maximum flow 8.2 gpm @ 60 psi per volume control when paired with Sensori thermostatic trim
