Grundfos CR 2010 AGJAV HQQV Vertical, Non-self Priming, Multistage, Inline, Centrifugal Pump with a Maximum Temperature of 194°F, a Rated Flow of 111 US GPM, a Rated Head of 561 Ft and Cast Iron Construction

CR 2010 AGJAV HQQV Vertical, Non-self Priming, Multistage, Inline, Centrifugal Pump with a Maximum Temperature of 194°F, a Rated Flow of 111 US GPM, a Rated Head of 561 Ft and Cast Iron Construction

CR 2010 AGJAV HQQV Vertical, non-self priming, multistage, inline, centrifugal pump for installation in pipe systems and mounting on a foundation. The pump has the following characteristics: Impellers and intermediate chambers are made of Stainless steel DIN W.Nr. DIN W.Nr. 1.4301. Pump head and base are made of Cast iron. The shaft seal has assembly length according to DIN 24960. Power transmission is via cast iron split coupling. Pipe work connection is via ANSI flanges. The motor is a 3 phase AC motor.

Technical:

• Speed for pump data: 3521 rpm
• Rated flow: 111 US gpm
• Rated head: 561 ft
• Shaft seal: HQQV
• Approvals on nameplate: NEMA

Material:

• Pump housing: Cast iron
• Pump housing: EN-JL1030
• Pump housing: ASTM A48-30 B
• Impeller: Stainless steel
• Impeller: DIN W.-Nr. 1.4301
• Impeller: AISI 304

Installation:

• Maximum ambient temperature: 104 °F
• Max pressure at stated temperature: 363 psi / 194 °F
• Max pressure at stated temperature: 363 / -4 psi/°F
• Flange standard: ANSI
• Pipe connection: 2"
• Pressure stage: Class 250
• Flange size for motor: 284TC

Liquid:

• Liquid temperature range: -4 .. 194 °F

Electrical Data:

• Motor type: BALDOR
• Number of poles: 2
• Power (P2) required by pump: 25.1 HP
• Phase: 3
• Enclosure class (IEC 34-5): 23
• Insulation class (IEC 85): B
