Grundfos CRN 321 AGGE KUBE Vertical, Non-self Priming, Multistage, Inline, Centrifugal Pump with a Rated Flow of 159 US GPM, a Rated Head of 67.6 Ft and Stainless Steel Construction

CRN 321 AGGE KUBE Vertical, Non-self Priming, Multistage, Inline, Centrifugal Pump with a Rated Flow of 159 US GPM, a Rated Head of 67.6 Ft and Stainless Steel Construction

CRN 321 AGGE KUBE Vertical, non-self priming, multistage, inline, centrifugal pump for installation in pipe systems and mounting on a foundation. The pump has the following characteristics: Impellers, intermediate chambers and outer sleeve are made of Stainless steel DIN W.Nr. DIN W.Nr. 1.4401. Pump head cover and base are made of Stainless steel DIN W.Nr. DIN W.Nr. 1.4408. The shaft seal has assembly length according to DIN 24960. Power transmission is via cast iron split coupling. Pipe work connection is via ANSI flanges/couplings. The motor is a 3 phase AC motor.

Technical:

• Speed for pump data: 3461 rpm
• Rated flow: 159 US gpm
• Rated head: 67.6 ft
• Shaft seal: KUBE
• Approvals on motor nameplate: UL Recognized Component, CSA

Material:

• Pump housing: Stainless steel
• Pump housing: DIN W.-Nr. 1.4408
• Pump housing: AISI 316 LN
• Impeller: Stainless steel
• Impeller: DIN W.-Nr. 1.4401
• Impeller: AISI 316

Installation:

• Maximum ambient temperature: 104 °F
• Max pressure at stated temperature: 232 psi / 250 °F
• Flange standard: ANSI
• Pipe connection: 2 1/2"
• Pressure stage: 150 Lb.
• Flange size for motor: 182TC

Liquid:

• Liquid temperature range: 32 .. 248 °F

Electrical Data:

• Motor type: 100BC
• Rated power - P2: 4.96 HP
• Main frequency: 60 Hz
• Rated voltage: 3 x 208-230/460 V
• Service factor: 1.15
• Rated current: 13.2-12/6 A
• Starting current: 103.9-94/47 A
• Cos phi - power factor: 0,93
• Rated speed: 3480-3510 rpm
• Motor efficiency at full load: 85,0 %
