Grundfos TP 10080/4 UGA BUBE Single Stage Centrifugal Inline Single Head Pump with a Rated Voltage of 3 X 208-230/460, a Rated Flow of 242 US GPM, a Rated Head of 22.3 Ft and Cast Iron Construction

TP 10080/4 UGA BUBE Single Stage Centrifugal Inline Single Head Pump with a Rated Voltage of 3 X 208-230/460, a Rated Flow of 242 US GPM, a Rated Head of 22.3 Ft and Cast Iron Construction

TP 10080/4 UGA BUBE Single stage centrifugal inline single head pump. The inline design with opposite suction and dis charge ports enables mounting in pipe work or on a concrete foundation. The shaft seal is a corrosion resistant maintenance free mechanical seal. The motor is a 3 phase AC motor.

Technical:

• Speed for pump data: 1760 rpm
• Rated flow: 242 US gpm
• Rated head: 22.3 ft
• Shaft seal: BUBE
• Maximum operating pressure: 145 psi
• Approvals on motor nameplate: UL Recognized Component, CSA

Material:

• Pump housing: Cast iron
• Pump housing: EN-JL1040
• Pump housing: ASTM 25 B
• Impeller: Stainless steel
• Impeller: DIN W.-Nr. 1.4301

Installation:

• Maximum ambient temperature: 104 °F
• Maximum operating pressure: 145 psi
• Flange standard: ANSI
• Pipe connection: 4"
• Pressure stage: 125 Lb.

Liquid:

• Liquid temperature range: 5 .. 284 °F

Electrical Data:

• Motor type: Baldor, TEFC
• Number of poles: 4
• Rated power - P2: 2.01 HP
• Main frequency: 60 Hz
• Rated voltage: 3 x 208-230/460 V
• Service factor: 1,15
• Rated current: 6,5-6,2/3,1 A
• Starting current: 48,7-44/22 A
• Cos phi - power factor: 77
• Rated speed: 1725 rpm
