Grundfos UP 1510 BUC7/LC Pump with 230°F Maximum Temperature, 7.73" Port-to-Port Length, a Max Flow of  6.6 US GPM, a Head Max of  6.56 Ft and Bronze Construction

UP 1510 BUC7/LC Pump with 230°F Maximum Temperature, 7.73" Port-to-Port Length, a Max Flow of  6.6 US GPM, a Head Max of  6.56 Ft and Bronze Construction

Product name:  UP 1510 BUC7/LC

Technical:

• Speed Number:  1
• Max flow:  6.6 US gpm
• Head max:  6.56 ft
• Maximum operating pressure  145 psi
• Approvals on nameplate:  UL, CSA
• Valve:  pump with built-in isolating and non-return valves

Material:

• Pump housing:  Bronze
• Impeller:  Composite, PES

Installation:

• Maximum ambient temperature:  104 °F
• Ambient max at 176°F liquid  176 °F
• Maximum operating pressure  145 psi
• Flange standard:  USA Sweat
• Type of connection:  Bronze Sweat
• Pipe connection:  3/4" Sweat
• Pressure stage:  10
• Port-to-port length:  7.72 in

Liquid:

• Liquid temperature range  35.6 .. 230 °F

Electrical Data:

• Number of poles:  2
• Max. power input:  25 W
• Rated power - P2:  0.04 HP
• Main frequency:  60 Hz
• Rated voltage:  1 x 115 V
• Current in speed 3  0.22 A
• Capacitor size - run  2 µF/400 V
• Insulation class (IEC 85):  F
• Motor protection:  CONTACT
• Thermal protect:  internal
